TSX-8510

Rmax

TSX-8510

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Board Insulation Board Insulation

Foam Board Foam Board

Polyisocyanurate Polyisocyanurate

Exterior Subterranean Wall, Sloped Ceiling Exterior Subterranean Wall, Sloped Ceiling

In Tilt-Up Wall Panels, Unfinished Floor In Tilt-Up Wall Panels, Unfinished Floor

Design Options

Product Description

Rmax TSX-8510 is an energy-efficient thermal insulation board composed of a closed-cell polyisocyanurate (polyiso) foam core bonded to glass fiber reinforced aluminum facers on both sides. The exposed side of the board has a white modified acrylic coating to provide an attractive interior finish. The other side is marked in production to ensure proper installation. The product has pre-engineered metal buildings; tilt-up construction; wood stud basement and crawl spaces; farm or storage buildings; parking structures; laminate panels and other similar applications.

Insulation

Width

Height

Thickness

Standard Sizes: 0-1/2", 0-3/4", 1", 1-1/4", 1-1/2", 1-3/4", 2", 2-1/4", 2-1/2", 3", 3-1/2", 3-3/4", 4", 4-1/2"

Manufacturer Design Notes

This product is designed for use without a thermal barrier (up to 4.5” on walls or 12” on ceilings) to provide an attractive interior finish.

Performance Data

R-Value Per Inch

Measure of the thermal resistance of the product per inch of thickness, imperial units.

°F·ft^2·h / BTU / inch

6.4

NRC Value

The Noise Reduction Coefficient values of this product

Fire Resistance

Amount of time the product can withstand fire

minutes

60

Flame Spread

As defined by the ASTM E84 testing standard

25

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

0.03

Product Density

lbs / ft^3

2

Compressive Strength

psi

20

Linear Shrinkage

The percent that a product shrinks, usually in response to heat.

%

1

Smoke Development

As defined by the ASTM E84 testing standard

450

R-Value

Measure of the thermal resistance of the product, imperial units.

°F·ft^2·h / BTU

3.2, 5, 6, 7.8, 9.6, 11.4, 13.1, 15.3, 16.7, 20.3, 23.9, 27.4, 31
