ECOMAXci FR Ply

Rmax

ECOMAXci FR Ply

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Board Insulation Board Insulation

Foam Board Foam Board

Polyisocyanurate Polyisocyanurate

Plywood Plywood

Sloped Ceiling Sloped Ceiling

In between Wood (or Steel) Studs, Unfinished Floor In between Wood (or Steel) Studs, Unfinished Floor

Design Options

Product Description

Rmax ECOMAXci FR Ply is a Class A energy-efficient thermal insulation board composed of a closed-cell polyisocyanurate (polyiso) foam core with glass fiber reinforced aluminum facers on both sides bonded to 5/8” or 3/4” fire retardant treated plywood.

Insulation

Width

Height

Thickness

Standard Sizes: 0-3/4", 1", 1-1/4", 1-1/2", 1-3/4", 2", 2-1/4", 2-3/4", 3-1/4", 3-3/4", 4-1/4", 4-3/4", 5-1/4"

Performance Data

R-Value Per Inch

Measure of the thermal resistance of the product per inch of thickness, imperial units.

°F·ft^2·h / BTU / inch

7.6

NRC Value

The Noise Reduction Coefficient values of this product

Fire Resistance

Amount of time the product can withstand fire

minutes

60

R-Value

Measure of the thermal resistance of the product, imperial units.

°F·ft^2·h / BTU

5.7, 5.9, 6.7, 6.9, 8.5, 8.7, 10.5, 14, 17.6, 21.2, 24.8, 28.3, 31.9

Flame Spread

As defined by the ASTM E84 testing standard

25

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

0.03

Product Density

lbs / ft^3

2

Compressive Strength

psi

20

Linear Shrinkage

The percent that a product shrinks, usually in response to heat.

%

1

Smoke Development

As defined by the ASTM E84 testing standard

450
