TSP

Rmax

TSP

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Rigid Panels Rigid Panels

Polyiso (Polyisocyanurate) Polyiso (Polyisocyanurate)

Ceiling Insulation, Exterior or Interior Wall Insulation, Roof Insulation Ceiling Insulation, Exterior or Interior Wall Insulation, Roof Insulation

Design Options

Product Description

Rmax TSP is an energy-efficient thermal insulation board composed of an environmentally sound closed-cell polyiso foam core bonded to glass fiber reinforced aluminum foil facers on each side. This insulation is suitable for use in walls, ceilings and some limited roofing applications in new construction for commercial, residential, agricultural and industrial buildings and in thermal retrofit construction within existing buildings.

Insulation

Width

Height

Thickness

Standard Sizes: 0-3/4", 1", 1-1/4", 1-1/2", 1-3/4", 2", 2-1/4", 2-1/2", 3", 3-1/2", 3-3/4", 4", 4-1/2"

Manufacturer Design Notes

Compressive strength available in 25 psi upon request. Less than 1” is standard at 16 psi. TSP is not recommended, nor warranted, for use as a commercial roof insulation directly under membrane systems.

Performance Data

R-Value Per Inch

Measure of the thermal resistance of the product per inch of thickness, imperial units.

°F·ft^2·h / BTU / inch

7

NRC Value

The Noise Reduction Coefficient values of this product

Fire Resistance

Amount of time the product can withstand fire

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

0.03

Smoke Development

As defined by the ASTM E84 testing standard

Units: (unitless)

450

Product Density

lbs / ft^3

2

Flame Spread

As defined by the ASTM E84 testing standard

Units: (unitless)

75

Compressive Strength

psi

20

Certifications

Energy Star

Certified
