RamShield 60

Barrett Company

RamShield 60

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Self-Adhering Membrane Self-Adhering Membrane

Polymer Polymer

Sloped Ceiling Sloped Ceiling

Concrete Surfaces, Exterior Subterranean Floor, Exterior Subterranean Wall, Floor, Interior Subterranean Wall, Masonry Surfaces, Specialty, Unfinished Floor, Wall Concrete Surfaces, Exterior Subterranean Floor, Exterior Subterranean Wall, Floor, Interior Subterranean Wall, Masonry Surfaces, Specialty, Unfinished Floor, Wall

Design Options

Product Description

RamShield® 60 is a 60 mil. thick (1.5 mm) self-adhering membrane for above and below-grade waterproofing. It features a woven polyethylene membrane coated on both sides with a uniquely engineered waterproofing blend. It
provides a self-adhered waterproofing membrane in above and below grade applications.

Sheet Width

Width

Standard Sizes: 5' 7"

Height

Thickness

Sheet Length

Width

Height

Standard Sizes: 1' 0"

Thickness

Thickness

Width

Height

Thickness

Standard Sizes: 0"

Manufacturer Design Notes

The area to be covered must be free from rust, grease, and oil. Additionally, the area must also be dry as residual moisture will interfere with proper adhesion.

Performance Data

Air Permeance

Rate of airflow through the barrier per square foot at a specified pressure difference

Product Weight Per Area

Roll Tensile Strength

Weight needed to break the roll, per inch of width

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

0.0152

Minimum Temperature Rating

The lowest temperature that the product has been confirmed to still function at.

°F

-20

Minimum Application Temperature

Minimum temperature that the product can be applied or installed

°F

40

Film Tensile Strength

Pressure required to break the film

psi

6242
