Air And Vapor Barrier Membrane Redzone Pro

Resisto

Air And Vapor Barrier Membrane Redzone Pro

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Vapor Retarder (Class I) Vapor Retarder (Class I)

Fully Adhering Fully Adhering

Bitumen Bitumen

Ceiling, Sloped Roof, Wall Ceiling, Sloped Roof, Wall

Concrete, Masonry Concrete, Masonry

Design Options

Product Description

Redzone Pro is a 1 mm (40 mils) self-adhesive through wall membrane designed for commercial and residential buildings. It ensures air and water vapor sealing. Redzone Pro is composed of elastomeric SBS bitumen and a trilaminate woven polyethylene facer. The tri laminated woven polyethylene is compatible with the use of sprayed polyurethane foam insulation.

Sheet Width

Width

Standard Sizes: 4", 6", 9", 1' 0", 1' 6", 3' 0"

Height

Thickness

Sheet Length

Width

Height

Standard Sizes: 6' 3"

Thickness

Thickness

Width

Height

Thickness

Standard Sizes: 0"

Manufacturer Design Notes

It is compatible with the use of spray polyurethane foam insulation and can also be used as a masonry flashing, transition membrane, and waterproofing the membrane around openings.

Performance Data

Product Weight Per Area

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

0.037

Roll Tensile Strength

Weight needed to break the roll, per inch of width

lbs / in

55

Minimum Temperature Rating

The lowest temperature that the product has been confirmed to still function at.

°F

-31

Minimum Application Temperature

Minimum temperature that the product can be applied or installed

°F

14

Air Permeance

Rate of airflow through the barrier per square foot at a specified pressure difference

cfm /ft^2 @ 1.57 psf

0.00001
