Hunter Xci CG and CG (Class A)

Hunter Panels

Hunter Xci CG and CG (Class A)

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Board Insulation Board Insulation

Foam Board Foam Board

Polyisocyanurate Polyisocyanurate

Sloped Ceiling Sloped Ceiling

Behind Masonry or Concrete Wall, Unfinished Floor Behind Masonry or Concrete Wall, Unfinished Floor

Design Options

Product Description

Xci CG is a high-thermal rigid insulation panel composed of a closed-cell polyisocyanurate foam core manufactured online to premium performance coated glass facers on both sides. It is designed for use in commercial wall applications to provide continuous insulation within the building envelope. It has superior fire performance, durability, dimensional stability, and resistance to mold growth.

Insulation

Width

Standard Sizes: 4' 0"

Height

Standard Sizes: 8' 0"

Thickness

Standard Sizes: 1", 1-1/2", 1-3/4", 2", 2-1/2", 3", 3-1/2", 4"

Manufacturer Design Notes

Can be applied to the exterior or interior of exterior walls, when separated from the interior by a 15-minute thermal barrier. Xci CG is not a structural sheathing; exterior cladding must be attached through to the framing.

Performance Data

R-Value Per Inch

Measure of the thermal resistance of the product per inch of thickness, imperial units.

°F·ft^2·h / BTU / inch

6

NRC Value

The Noise Reduction Coefficient values of this product

Fire Resistance

Amount of time the product can withstand fire

Product Weight Per Area

Varies if the product comes in multiple thicknesses.

lbs / ft^2

0.38, 0.91

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

1

Flame Spread

As defined by the ASTM E84 testing standard

75

Compressive Strength

psi

20, 25

Linear Shrinkage

The percent that a product shrinks, usually in response to heat.

%

2

Smoke Development

As defined by the ASTM E84 testing standard

450

Minimum Recycled

The minimum amount of the product's input materials that come from recycled sources

%

9

R-Value

Measure of the thermal resistance of the product, imperial units.

°F·ft^2·h / BTU

6, 9, 10, 12.1, 15.3, 18.5, 21.7, 25
