All of our information is sourced from manufacturer data.

ICA-LITE EPS Type VIII

Insulation Corporation of America

ICA-LITE EPS Type VIII

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Board Insulation Board Insulation

Foam Board Foam Board

EPS (Expanded Polystyrene) EPS (Expanded Polystyrene)

Exterior Subterranean Wall, Roof, Sloped Ceiling Exterior Subterranean Wall, Roof, Sloped Ceiling

Design Options

Product Description

ICA-LITE brand expanded polystyrene insulation is a rigid, closed-cell, lightweight plastic foam. EPS is available in several compressive strengths to withstand load and back-fill forces. This closed-cell structure provides minimal water absorption and low vapor permanence.Thickness available between 1/4″ to 54″.

Insulation

Width

Standard Sizes: 2' 0", 4' 0"

Height

Standard Sizes: 8' 0", 18' 0"

Thickness

Standard Sizes: 0-1/4", 0-1/2", 1", 1-1/2", 2", 2-1/2", 3", 3-1/2", 4", 4-1/2", 5", 5-1/2", 6", 6-1/2", 7", 7-1/2", 8", 8-1/2", 9", 9-1/2", 10", 10-1/2", 11", 11-1/2", 12", 12-1/2", 13", 13-1/2", 14", 14-1/2", 15", 15-1/2", 16", 16-1/2", 17", 17-1/2", 18", 18-1/2", 19", 19-1/2", 20", 20-1/2", 21", 21-1/2", 22", 22-1/2", 23", 23-1/2", 24", 24-1/2", 25"

Performance Data

R-Value Per Inch

Measure of the thermal resistance of the product per inch of thickness, imperial units.

°F·ft^2·h / BTU / inch

3.92

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

NRC Value

The Noise Reduction Coefficient values of this product

Fire Resistance

Amount of time the product can withstand fire

Tensile Strength

psf

2448, 3024

Smoke Development

As defined by the ASTM E84 testing standard

450

Product Density

lbs / ft^3

1.15

Flame Spread

As defined by the ASTM E84 testing standard

25

Dimensional Stability

The percent that a product's dimensions vary due to aging or environmental conditions.

%

2

Compressive Strength

psi

13, 18

Insulation Corporation of America
