Universal Primer Free Membrane

Protecto Wrap Co.

Universal Primer Free Membrane

One-Click Request

Acelab will find & contact reps to deliver answers to your inbox.

Overview

Self-Adhering Membrane Self-Adhering Membrane

Polymer Polymer

Sloped Ceiling, Vapor Retarder, Waterproofing Sloped Ceiling, Vapor Retarder, Waterproofing

Concrete Surfaces, Exterior Subterranean Floor, Exterior Walls Only, Masonry Surfaces, Unfinished Floor Concrete Surfaces, Exterior Subterranean Floor, Exterior Walls Only, Masonry Surfaces, Unfinished Floor

Design Options

Product Description

It’s specifically designed for use as a thru-wall flashing, full wall waterproofing membrane, seals skirt board-foundation to wood frame interface, ICF waterproofing membrane and as an air and vapor barrier.

Sheet Width

Width

Standard Sizes: 3", 4", 6", 9", 1' 0", 1' 6", 2' 0", 3' 0"

Height

Thickness

Sheet Length

Width

Height

Standard Sizes: 4' 2"

Thickness

Thickness

Width

Height

Thickness

Standard Sizes: 0"

Manufacturer Design Notes

Compatible with and will adhere to most construction surfaces, wood, concrete, CMU block, OSB, plywood, glass mat exterior sheathing products, foam insulation board, ICF and metal.

Performance Data

Product Weight Per Area

Roll Tensile Strength

Weight needed to break the roll, per inch of width

Water Vapor Transmission

An imperial perm is defined as 1 grain of water vapor per hour, per square foot, per inch of mercury

perm (imperial)

0.272

Minimum Temperature Rating

The lowest temperature that the product has been confirmed to still function at.

°F

-45

Minimum Application Temperature

Minimum temperature that the product can be applied or installed

°F

-20

Film Tensile Strength

Pressure required to break the film

psi

24

Air Permeance

Rate of airflow through the barrier per square foot at a specified pressure difference

cfm /ft^2 @ 1.57 psf

0.00001
