Loewen Windows

    All-Wood Awning Window

    $$$$

    Price categories are relative and based on product material

    Awning

    Window Type

    Wood

    Material

    Replacement, Residential

    Building Sector

    Available in All of US, Canada

    Made in Canada

    Energy Star

    Gold

    Updated: 02.23.2022

    Rep Image

    Got Questions?

    Acelab will connect you to a rep that will help you take the next step with just a simple click.

    All-Wood
    All-Wood
    All-Wood

    Design Options

    All of our information is sourced from manufacturer data.

    Product Type Image

    Series Description

    Authenticity is at the core of our product design, we continuously utilize genuine materials like Coastal Douglas Fir, Honduran Mahogany, and White Oak.

    Dimensions

    Type Min Width Max Width Min Height Max Height Thickness
    Frame 20-7/16" 142-1/2" 17-3/16" 75-5/16" 4-9/16"

    Finish Colors

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    • Cedar
    • Cinnamon
    • Clear
    • Coastal Grey
    • Ebony
    • Jet Black
    • Oxford White
    • Red Mahogany
    • Rich Mahogany
    • Spanish
    • Spanish Oak
    • Tuscon
    • Western

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    Hardware Finishes

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    • Antique Brass
    • Bright Brass
    • Brushed Chrome
    • Faux Bronze
    • Linen
    • Matte Black
    • Oil Rubbed Bronze
    • Rustic Bronze
    • Satin Nickel
    • Unlacquered Brass
    • White

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    Hardware

    concealed multipoint lock handle

    concealed multipoint lock handle



    concealed multipoint lock handle
    Push Out / Contemporary
    Push Out / Standard

    Grid Profiles

    Simulated Divided Lite (SDL)

    Simulated Divided Lite (SDL)

    Width: 5/8", 3/4", 7/8", 1-1/8", 2"

    Simulated Divided Lite (SDL)

    Grid Patterns

    Colonial

    Colonial



    Colonial
    Custom
    Prairie

    Decorative Glass

    Colored

    Colored



    Colored
    Frosted
    Obscured
    Textured
    Translucent

    Composition

    Bay and Bow

    Bay and Bow



    Bay and Bow
    Common Jambs

    Add-Ons

    Extension Jambs

    Extension Jambs



    Extension Jambs
    Insect Screens
    Nail Fins

    Performance Data

    Performance Class & Grade

    Class
    CW (Commercial)
    Grade
    70
    Test Size
    -
    Class Grade (psf) Color gradient is representative of strength Minimum Test Size
    R (Residential)
    10 20 30 40 50 60 70 80 90 100
    -
    LC (Light Commercial)
    10 20 30 40 50 60 70 80 90 100
    -
    CW (Commercial)
    70
    10 20 30 40 50 60 70 80 90 100
    -
    AW (Architectural)
    10 20 30 40 50 60 70 80 90 100
    -

    Glazing

    Type Features Energy Star U-Factor Solar Heat Coefficient Visible Transmittance Fire Rating
    dual glazing LoE 180 Double Pane, Low-E Coating North Central 0.3 0.4 0.49 -
    Dual Glazing LoE 180 Argon, Double Pane, Low-E Coating North Central, Northern 0.27 0.4 0.49 -
    Dual Glazing LoE2 272 Argon, Double Pane, Low-E Coating North Central, Northern 0.27 0.26 0.45 -
    Dual Glazing LoE2 272 Double Pane, Low-E Coating North Central 0.3 0.26 0.45 -
    Dual Glazing LoE3 340 Argon, Double Pane, Low-E Coating North Central, Northern, South Central, Southern 0.26 0.11 0.24 -
    Dual Glazing LoE3 340 Double Pane, Low-E Coating North Central, South Central, Southern 0.29 0.12 0.24 -
    Dual Glazing LoE3 366 Argon, Double Pane, Low-E Coating North Central, Northern, South Central, Southern 0.26 0.17 0.4 -
    Dual Glazing LoE3 366 Double Pane, Low-E Coating North Central, South Central, Southern 0.29 0.18 0.4 -
    Triple Glazing LoE 180 Argon, Low-E Coating, Triple Pane North Central, Northern 0.21 0.39 0.45 -
    Triple Glazing LoE 180 Low-E Coating, Triple Pane North Central, Northern 0.23 0.39 0.45 -
    Triple Glazing LoE2 272 Argon, Low-E Coating, Triple Pane North Central, Northern 0.2 0.29 0.41 -
    Triple Glazing LoE2 272 Low-E Coating, Triple Pane North Central, Northern 0.22 0.29 0.41 -
    Triple Glazing LoE3 340 Argon, Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.17 0.1 0.21 -
    Triple Glazing LoE3 340 Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.19 0.1 0.21 -
    Triple Glazing LoE3 366 Argon, Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.17 0.15 0.35 -
    Triple Glazing LoE3 366 Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.19 0.15 0.35 -

    Custom Glass Available

    U-Factor

    0.1
    0.2
    0.3
    0.4
    0.5
    0.6
    0.7
    0.8
    0.9
    0.17 0.3

    Solar Heat Gain Coefficient

    0.1
    0.2
    0.3
    0.4
    0.5
    0.6
    0.7
    0.8
    0.9
    0.1 0.4
