Loewen Windows

    Metal-Clad Awning Window

    $$

    Price categories are relative and based on product material

    Awning

    Window Type

    Aluminum-Clad Wood

    Material

    Replacement, Residential

    Building Sector

    Available in All of US, Canada

    Made in Canada

    Energy Star

    Gold

    Updated: 01.27.2022

    Rep Image

    Got Questions?

    Acelab will connect you to a rep that will help you take the next step with just a simple click.

    Metal-Clad
    Metal-Clad
    Metal-Clad

    Design Options

    All of our information is sourced from manufacturer data.

    Product Type Image

    Series Description

    Heavy duty exterior metal cladding comprised of extruded aluminum is available in a variety of finishes.

    Product Description

    Their extruded aluminum cladding is intricately detailed and withstands serious impact without sustaining damage.

    Dimensions

    Type Min Width Max Width Min Height Max Height Thickness
    Frame 20-7/16" 142-1/2" 16-1/2" 71-5/8" 4-9/16"

    Finish Colors

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    • Alpine White
    • Black
    • Cedar
    • Champagne
    • Cinnamon
    • Clear
    • Clear
    • Coastal Grey
    • Copper
    • Corretto
    • Country Road
    • Cranberry
    • Dark Bronze
    • Dover Grey
    • Ebony
    • Extra Dark Bronze
    • Graphite
    • Hartford Green
    • Jet Black
    • Kodiak
    • Light Bronze
    • Linen
    • Medium Bronze
    • Midnight Bronze
    • Oxford White
    • Red Mahogany
    • Rich Mahogany
    • Riverbed
    • Spanish
    • Spanish Oak
    • Steel Matte Black
    • Stone Grey
    • Storm Grey
    • Tuscany Brown
    • Tuscon
    • Western
    • White
    • Woodland Green

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    Hardware Finishes

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    • Antique Brass
    • Bright Brass
    • Brushed Chrome
    • Faux Bronze
    • Linen
    • Matte Black
    • Oil Rubbed Bronze
    • Satin Nickel
    • White

    All finish samples shown are for visualization purposes only and are not intended to be an accurate representation of the actual finish. For exact color, please contact manufacturer directly for finish samples.

    Hardware

    Crank and Cover / Contemporary

    Crank and Cover / Contemporary



    Crank and Cover / Contemporary
    Crank and Cover / Provence
    Crank and Cover / Tango

    Grid Profiles

    Simulated Divided Lite (SDL)

    Simulated Divided Lite (SDL)

    Width: 5/8", 3/4", 7/8", 1-1/8", 2"

    Simulated Divided Lite (SDL)

    Grid Patterns

    Colonial

    Colonial



    Colonial
    Custom
    Prairie

    Decorative Glass

    Colored

    Colored



    Colored
    Frosted
    Obscured
    Textured
    Translucent

    Trims

    Adams

    Adams



    Adams
    Brickmould
    Clad Frame Extension
    Flat
    Kerf
    Nose & Cove
    Williamsburg

    Composition

    Bay and Bow

    Bay and Bow



    Bay and Bow
    Common Jambs

    Add-Ons

    Extension Jambs

    Extension Jambs



    Extension Jambs
    Insect Screens
    Nail Fins

    Performance Data

    Performance Class & Grade

    Class
    CW (Commercial)
    Grade
    70
    Test Size
    -
    Class Grade (psf) Color gradient is representative of strength Minimum Test Size
    R (Residential)
    10 20 30 40 50 60 70 80 90 100
    -
    LC (Light Commercial)
    10 20 30 40 50 60 70 80 90 100
    -
    CW (Commercial)
    70
    10 20 30 40 50 60 70 80 90 100
    -
    AW (Architectural)
    10 20 30 40 50 60 70 80 90 100
    -

    Glazing

    Type Features Energy Star U-Factor Solar Heat Coefficient Visible Transmittance Fire Rating
    Dual Glazing LoE 180 Argon, Double Pane, Low-E Coating Northern 0.29 0.43 0.52 -
    Dual Glazing LoE 180 Double Pane, Low-E Coating - 0.32 0.43 0.52 -
    Dual Glazing LoE2 272 Argon, Double Pane, Low-E Coating North Central 0.29 0.28 0.48 -
    Dual Glazing LoE2 272 Double Pane, Low-E Coating - 0.31 0.28 0.48 -
    Dual Glazing LoE3 340 Argon, Double Pane, Low-E Coating North Central, South Central, Southern 0.28 0.12 0.26 -
    Dual Glazing LoE3 340 Double Pane, Low-E Coating Southern 0.31 0.13 0.26 -
    Dual Glazing LoE3 366 Argon, Double Pane, Low-E Coating North Central, South Central, Southern 0.28 0.18 0.43 -
    Dual Glazing LoE3 366 Double Pane, Low-E Coating Southern 0.31 0.19 0.43 -
    Triple Glazing LoE 180 Argon, Low-E Coating, Triple Pane Northern 0.22 0.41 0.48 -
    Triple Glazing LoE 180 Low-E Coating, Triple Pane Northern 0.24 0.41 0.48 -
    Triple Glazing LoE2 272 Argon, Low-E Coating, Triple Pane North Central, Northern 0.21 0.31 0.43 -
    Triple Glazing LoE2 272 Low-E Coating, Triple Pane North Central, Northern 0.24 0.31 0.43 -
    Triple Glazing LoE3 340 Argon, Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.18 0.11 0.23 -
    Triple Glazing LoE3 340 Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.2 0.11 0.23 -
    Triple Glazing LoE3 366 Argon, Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.18 0.16 0.38 -
    Triple Glazing LoE3 366 Low-E Coating, Triple Pane North Central, Northern, South Central, Southern 0.2 0.16 0.38 -

    Custom Glass Available

    U-Factor

    0.1
    0.2
    0.3
    0.4
    0.5
    0.6
    0.7
    0.8
    0.9
    0.18 0.32

    Solar Heat Gain Coefficient

    0.1
    0.2
    0.3
    0.4
    0.5
    0.6
    0.7
    0.8
    0.9
    0.11 0.43

    Loewen Windows

    77 Hwy. 52 W. P. O. Box 2260 Steinbach, MB R0A 2A0

    (800) 563-9367

    www.loewen.com
